STANDARD: NPT or NPTF as specified 45 deg. Chamfer, working face as listed in table.
OPTIONAL: Special working face, bronze bushings.
| 1/16 – 27 | .375 |
| 1/8 – 27 | .375 |
| ¼ – 18 | .562 |
| 3/8 – 18 | .562 |
| ½ – 14 | .712 |
| ¾ – 14 | .724 |
| 1 – 11 ½ | .900 |
| 1 ¼ – 11 ½ | .924 |
| 1 ½ – 11 ½ | .941 |
